BJVE-426-180 Electric Vibroflot
180kW electric vibroflot specially designed for foundation reinforcement, with strong penetration and stable operation, it has been sold in over 60 countries for airports, ports, highways and municipal ground treatment.
- It is fitted with an 180kW high-output motor, offering strong penetration and high construction efficiency
- Thickened high carbon alloy steel body with a reinforced wear-resistant layer
- It operates stably from -30℃to 70℃ and suits all harsh construction conditions
- Easily matched with crawler cranes, truck cranes and piling frames
- 12-month global warranty with quick delivery of spare parts worldwide
Tailored BJVE-426-180 Vibroflot, all-round support
We provide personalized customization for BJVE-426-180 vibroflots. Our engineers adjust output power, machine dimensions and components according to your geological conditions, pile depth and project cost. We provide full support including early model consultation, pre-delivery factory inspection, overseas technicians’ installation training and consistent supply of replacement parts.
BJVE-426-180 Vibroflot: Low Faults, Long Runtime
All BJVE-426-180 vibroflots pass strict production checks and performance tests. Key parts are imported from Germany and Sweden to reduce the failure rate. High-carbon alloy steel vibrating bodies deliver a far longer service lifespan under continuous high-frequency vibration. 50 years of manufacturing experience ensures stable, durable equipment that cuts your maintenance costs during long-term construction.
Global Full After-Sales Support for BVEM Vibroflots
We maintain an international service network to deliver reliable after-sales support for all BJVE vibroflot models. We can send experienced technicians to your construction location to supervise equipment setup and teach your staff standard operating procedures. Any machine breakdown will get a reply from our service crew in one hour, with full troubleshooting plans ready within two days. We arrange fast shipment of replacement parts to worksites around the world, minimizing idle time on your projects.
BJVE-426-180 Vibroflot Core Advantages
Made for onshore foundation projects, this practical manual explains soil matching, matched equipment, dry/wet construction workflows and cost-saving tips for the 180kW electric vibroflot.
- Supports both dry and wet compaction modes. Inland construction sites won’t require extra water supply
- Compatible extension rods enable flexible adjustment of pile depth
- Equipped with a universal connector for fast machine transfer across different construction sites.
Technical Specifications
| Parameter | Specification |
| Model | BJVE-426-180 |
| Outer Diameter | 426 mm |
| Width | 676 mm |
| Total body length | 3020 mm |
| Shaft connection size | 510 mm |
| Extension rod optional length | 5/6/7/10 m |
| Power | 180 kW |
| Rated Current | 356 A |
| Rated Speed | 1450 rpm |
| Max Amplitude | 22 mm |
| Centrifugal Force | 280kN |
| Weight | 2320kg |
| Applicable Soil Types | Loose sand,clay,silt,gravel,fill&collapsible loess |
| Certification | CE&CCC |
You can turn to our technical staff for free model matching suggestions. We tailor equipment solutions after reviewing your geotechnical reports, target pile depth and on-site limits to get the best possible working results.
We carry both versions. Our team will run a full cost comparison and suggest the most suitable unit after analyzing your actual site working conditions.
Absolutely. Deep high-frequency vibration compacts loose sand layers tightly, effectively eliminating liquefaction risks and maintaining stable foundations.
Our technicians provide free commissioning and training. We also ship spare parts quickly to worksites worldwide under a full one-year machine warranty.
